It can be sanded on mirrors and glass. Peel off the coating layer and sand it is formed at one time to improve the processing efficiency.
Marking
Marking can be made on static surfaces of metallic and non-metallic materials.
Punching
It can be used for glass and mirror processing special-shaped holes, round holes, waist-shaped holes, and square holes to meet diverse needs.
Laser source type
Tonghui customized laser
Working size
1300mm×2500mm
Power
120w
File Format
dxf/plt/ai/jpg/bmp/png
QR code format
AZTEC/DATA MATRTX/PDF 417/QR CODE
Supported languages
Chinese/English/Italian/Portuguese/Korean
Equipment advantages
Precision transmission system
The transmission design of rack and screw rod not only significantly enhances the stability of operation, but also accurately improves the machining accuracy
High-performanceservo motors
Equipped with ahigh-efficiency servo motor as the power,it achieves a fast response and ensures high precision in the machining process.
Versatile work surfaces
The table design integrates adjustable sliders and zoned dust collection systems to fully adapt to the processing needs of parts of different sizes and improve operational flexibility.
Convenient control experience
The independent operation platform makes the operation more convenient and the staff can move freely.
Advanced head cooling technology
The machine head is equipped with an air cooling system, which provides instant cooling for glass products during the processing,significantly reducing the occurrence of edge cracking and bursting.
